MagnumForce

Name: MagnumForce
SKU: 2002539
Availability: OutOfStock

MagnumForce

Product Technical Information

Technical Drawings

Variants information

Product downloads and manuals

Select Model

MagnumForce 10t 4m

Item Number: 2002539

Price under request

You can ask for a quote adding the item to the shopcart

Price under request

Product advantages

Product Technical Information

Dimension L1 max
60 m
Safety Factor
7:1
Main Material
High molecular weight polyethylene (HMPE)
Packaging Unit (PU)
pcs
Temperature Range
- 40 tot + 70°C
Packaging Unit (PU) Content
1
Color
Orange

Technical Drawings

Variants information

Item Number	Item Name	Price	Dimension L1 min	Contact Thickness Under Load	Weight per Meter	Contact Width Under Load
2002539	MagnumForce 10t 4m	Price under request You can ask for a quote adding the item to the shopcart	2 m	7 mm	0.8 kg/m	70 mm
2002540	MagnumForce 10t 5m	Price under request You can ask for a quote adding the item to the shopcart	2 m	7 mm	0.8 kg/m	70 mm
2002541	MagnumForce 10t 6m	Price under request You can ask for a quote adding the item to the shopcart	2 m	7 mm	0.8 kg/m	70 mm
2002542	MagnumForce 10t 7m	Price under request You can ask for a quote adding the item to the shopcart	2 m	7 mm	0.8 kg/m	70 mm
2002543	MagnumForce 10t 8m	Price under request You can ask for a quote adding the item to the shopcart	2 m	7 mm	0.8 kg/m	70 mm
2002544	MagnumForce 20t 4m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2002545	MagnumForce 20t 5m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2002546	MagnumForce 20t 6m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2002547	MagnumForce 20t 7m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2002548	MagnumForce 20t 8m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2002549	MagnumForce 30t 4m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2002550	MagnumForce 30t 5m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2002551	MagnumForce 30t 6m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2002552	MagnumForce 30t 7m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2002553	MagnumForce 30t 8m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2002554	MagnumForce 40t 4m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2002555	MagnumForce 40t 5m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2002556	MagnumForce 40t 6m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2002557	MagnumForce 40t 7m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2002558	MagnumForce 40t 8m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2002559	MagnumForce 50t 4m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2002560	MagnumForce 50t 5m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2002561	MagnumForce 50t 6m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2002562	MagnumForce 50t 7m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2002563	MagnumForce 50t 8m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2008377	MagnumForce 60t 4m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm
2008378	MagnumForce 60t 5m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm
2008379	MagnumForce 60t 6m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm
2008380	MagnumForce 60t 7m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm
2008381	MagnumForce 60t 8m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm
2008382	MagnumForce 80t 4m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2008383	MagnumForce 80t 5m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2008384	MagnumForce 80t 6m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2008385	MagnumForce 80t 7m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2008386	MagnumForce 80t 8m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2008387	MagnumForce 100t 4m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2008388	MagnumForce 100t 5m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2008389	MagnumForce 100t 6m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2008390	MagnumForce 100t 7m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2008391	MagnumForce 100t 8m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2026518	MagnumForce 10t 3m	Price under request You can ask for a quote adding the item to the shopcart	2 m	7 mm	0.8 kg/m	70 mm
2026519	MagnumForce 10t 2m	Price under request You can ask for a quote adding the item to the shopcart	2 m	7 mm	0.8 kg/m	70 mm
2026520	MagnumForce 20t 2m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2026521	MagnumForce 20t 3m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2026522	MagnumForce 20t 9m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2026523	MagnumForce 20t 10m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2026525	MagnumForce 20t 12m	Price under request You can ask for a quote adding the item to the shopcart	2 m	18 mm	1.6 kg/m	91 mm
2026526	MagnumForce 30t 2m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2026527	MagnumForce 30t 3m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2026528	MagnumForce 30t 9m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2026529	MagnumForce 30t 10m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2026531	MagnumForce 30t 12m	Price under request You can ask for a quote adding the item to the shopcart	3 m	20 mm	2.6 kg/m	115 mm
2026532	MagnumForce 40t 3m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2026535	MagnumForce 40t 9m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2026536	MagnumForce 40t 10m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2026538	MagnumForce 40t 12m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2026539	MagnumForce 50t 3m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2026540	MagnumForce 50t 9m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2026541	MagnumForce 50t 10m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2026543	MagnumForce 50t 12m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2026544	MagnumForce 60t 3m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm
2026546	MagnumForce 60t 10m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm
2026549	MagnumForce 80t 3m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2026551	MagnumForce 80t 10m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2026553	MagnumForce 80t 12m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2026554	MagnumForce 100t 3m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2026555	MagnumForce 100t 9m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2026556	MagnumForce 100t 10m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2026557	MagnumForce 100t 11m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2026558	MagnumForce 100t 12m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2027190	MagnumForce 100t 14m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2031421	MagnumForce 100t 22m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2032555	MagnumForce 40t 2.5m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2032556	MagnumForce 40t 2m	Price under request You can ask for a quote adding the item to the shopcart	3 m	22 mm	3.4 kg/m	135 mm
2033146	MagnumForce 50t 2m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	4.2 kg/m	152 mm
2033147	MagnumForce 80t 2m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	6.1 kg/m	200 mm
2033148	MagnumForce 100t 2m	Price under request You can ask for a quote adding the item to the shopcart	3 m	35 mm	7.1 kg/m	190 mm
2033173	MagnumForce 60t 2m	Price under request You can ask for a quote adding the item to the shopcart	3 m	23 mm	5.0 kg/m	165 mm

Product downloads and manuals

File
(de de_CH en en_US fr es it nl fr_FR)
Download
