Product Technical Information

Dimension L1 max
50 m
Safety Factor
8:1
Belt Layers
2
Main Material
Polyester
Norms
AS 1353.1
Packaging Unit (PU)
pcs
Temperature Range
-40°C / +100°C
Packaging Unit (PU) Content
1

Technical Drawings

Variants information

Item Number	Item Name	Price	Dimension L1 min	Minimum Load Edge Radius	Color
2029124	B-Series 250kg 2.0m	Price under request You can ask for a quote adding the item to the shopcart	0.6 m	12 mm	Olive
2029125	B-Series 250kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	0.6 m	12 mm	Olive
2029126	B-Series 250kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	0.6 m	12 mm	Olive
2029127	B-Series 250kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	0.6 m	12 mm	Olive
2029128	B-Series 250kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	0.6 m	12 mm	Olive
2029129	B-Series 250kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	0.6 m	12 mm	Olive
2029131	B-Series 500kg 1.5m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029132	B-Series 500kg 2.0m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029133	B-Series 500kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029134	B-Series 500kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029135	B-Series 500kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029136	B-Series 500kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029137	B-Series 500kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029138	B-Series 500kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	0.7 m	12 mm	Green
2029141	B-Series 1000kg 1.5m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029142	B-Series 1000kg 2.0m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029143	B-Series 1000kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029144	B-Series 1000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029145	B-Series 1000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029146	B-Series 1000KG 5.0m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029147	B-Series 1000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029148	B-Series 1000kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029149	B-Series 1000kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	0.82 m	15 mm	Purple
2029150	B-Series 2000kg 1.5m	Price under request You can ask for a quote adding the item to the shopcart	1.1 m	22.5 mm	Green
2029151	B-Series 2000kg 2.0m	Price under request You can ask for a quote adding the item to the shopcart	1.1 m	22.5 mm	Green
2029152	B-Series 2000kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	1.1 m	22.5 mm	Green
2029153	B-Series 2000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	1.1 m	22.5 mm	Green
2029154	B-Series 2000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	1.1 m	22.5 mm	Green
2029155	B-Series 2000kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	1.1 m	22.5 mm	Green
2029156	B-Series 2000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	1.1 m	22.5 mm	Green
2029157	B-Series 3000kg 1.5m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029158	B-Series 3000kg 2.0m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029159	B-Series 3000kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029160	B-Series 3000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029161	B-Series 3000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029162	B-Series 3000kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029163	B-Series 3000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029164	B-Series 3000kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029165	B-Series 3000kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	1.25 m	24 mm	Yellow
2029166	B-Series 4000kg 1.5m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029167	B-Series 4000kg 2.0m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029168	B-Series 4000kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029169	B-Series 4000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029170	B-Series 4000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029171	B-Series 4000kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029172	B-Series 4000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029173	B-Series 4000kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029174	B-Series 4000kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	1.5 m	24 mm	Grey
2029175	B-Series 5000kg 1.5m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029176	B-Series 5000kg 2.0m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029177	B-Series 5000kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029178	B-Series 5000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029179	B-Series 5000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029180	B-Series 5000kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029181	B-Series 5000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029182	B-Series 5000kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029183	B-Series 5000kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	1.7 m	24 mm	Red
2029184	B-Series 6000kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	2.17 m	24 mm	Brown
2029185	B-Series 6000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	2.17 m	24 mm	Brown
2029186	B-Series 6000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	2.17 m	24 mm	Brown
2029187	B-Series 6000kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	2.17 m	24 mm	Brown
2029188	B-Series 6000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	2.17 m	24 mm	Brown
2029189	B-Series 6000kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	2.17 m	24 mm	Brown
2029190	B-Series 6000kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	2.17 m	24 mm	Brown
2029191	B-Series 8000kg 2.5m	Price under request You can ask for a quote adding the item to the shopcart	2.65 m	27 mm	Blue
2029192	B-Series 8000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	2.65 m	27 mm	Blue
2029193	B-Series 8000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	2.65 m	27 mm	Blue
2029194	B-Series 8000kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	2.65 m	27 mm	Blue
2029195	B-Series 8000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	2.65 m	27 mm	Blue
2029196	B-Series 8000kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	2.65 m	27 mm	Blue
2029197	B-Series 8000kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	2.65 m	27 mm	Blue
2029198	B-Series 10000kg 3.0m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	Orange
2029199	B-Series 10000kg 4.0m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	Orange
2029200	B-Series 10000kg 5.0m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	Orange
2029201	B-Series 10000kg 6.0m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	Orange
2029202	B-Series 10000kg 7.0m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	Orange
2029203	B-Series 10000kg 8.0m	Price under request You can ask for a quote adding the item to the shopcart	3 m	27 mm	Orange
