Select Model
VLBS 1.5
Item Number: 2009235
Price under request
You can ask for a quote adding the item to the shopcart
Price under request
Select Model
VLBS 1.5
Item Number: 2009235
Price under request
You can ask for a quote adding the item to the shopcartRecommendations for Use
Check the attachment points regularly and before each commissioning for cracks in the welding seam, severe corrosion, wear, deformations, etc.
The mounting location shall be selected in such a way that the forces applied can be absorbed by the base material without deformations impairing safety; if necessary, specify minimum sheet thickness. The weld-on material shall be suitable for welding and free from impurities, oil, paint, etc.
Arrange the lifting point for single fall anchorage vertically above the load centre.
Arrange the attachment points for multiple-strand slings evenly in one plane around the load's centre of gravity.
Product Technical Information
-
Safety Factor
4:1 -
Main Material
Steel -
Norms
EN 1677-1 ISO 12100 -
Packaging Unit (PU)
pcs -
Temperature Range
-20° C to + 200° C -
Packaging Unit (PU) Content
1 -
Color
Pink
Variants information
| Item Number | Item Name | Price | Stock | Purchase | Product Name | WLL t Angle 0° | WLL t Angle 90° |
|---|---|---|---|---|---|---|---|
|
2009235
|
VLBS 1.5 |
Price under request You can ask for a quote adding the item to the shopcart |
|
1.5 t | 1.5 t | ||
|
2009253
|
VLBS 2.5 |
Price under request You can ask for a quote adding the item to the shopcart |
|
2.5 t | 2.5 t | ||
|
2009254
|
VLBS 4 |
Price under request You can ask for a quote adding the item to the shopcart |
|
4 t | 4 t | ||
|
2009255
|
VLBS 6.7 |
Price under request You can ask for a quote adding the item to the shopcart |
|
6.7 t | 6.7 t | ||
|
2009256
|
VLBS 10 |
Price under request You can ask for a quote adding the item to the shopcart |
|
10 t | 10 t | ||
|
2009257
|
VLBS 16 OF |
Price under request You can ask for a quote adding the item to the shopcart |
|
16 t | 16 t |
